Teknik Parametreler
| Modeli: KN-3710DE | |
|---|---|
| Maks. Çalışma Boyutu X/Y/Z(mm) | 4200*2150*100 |
| Maks. Hareket HızıX/Y/Z(m/dak) | 80/80/30 |
| Vakum Alanı | 6 |
| Vakum Kapasitesi(m³/h) | 244*2 |
| Toz Başlığının Boyutu ve Adeti | Ø200*1 |
| Takım Magazini – Revoler tipi | 12 |
| Toplam Güç(kW) | 32,8 |
| Ana Freze gücü(kW)-ISO30 | 12.0 |
| Delme Kafası | 5+5 Delme Kafası |
| Makine Boyutu(L)(W)(H)(mm) | 5600L*3350W*2415H |
Ürün Videosu
DELTA CONTROL UNIT
Control System
Delta bus control system; Intutitve control panel, easy operation, fast reponse,and high position accuracy;Available for remote control, convenence in maintenenc and management;built in graphic software,fast drawing and optimized path simulation
REVOLVER TOOL CHANGER
Tools Changers
12-post rotary ATC,
Quick changeover and high accuracy and stability
VERTICAL BORING UNIT
Boring Unit
10V drilling head for D model,
Stonger pressure on drilling enures stable drill and drill depth, to realize efficient work
INDUSTRIAL FRAME with VACUUM CHAMBER
Vacuum chanmber,
Rigid framethe machine frame with annealing treatment ensures stable and reliable running;
Specified vacuum tables guarantee stronger absorption
ÖNE ÇIKANLAR
TOOL SENSOR
Tools Pre-setter
High precision in tools measurement
ÖNE ÇIKANLAR
ELECTRSPINDLE
Spindle Specifications;
PSK 12KW ISO30 spindle，
High power,
high accuracy and long service life
ÖNE ÇIKANLAR
PUSHER
